Industry Insight: Led White Lighting

Introduction & Market Demand for Commercial LED Lighting

Market Drivers Shaping Modern Lighting Solutions

The global commercial and industrial lighting sector is undergoing rapid transformation driven by stringent energy efficiency regulations, rising demand for sustainable solutions, and the integration of smart building technologies. According to industry reports, the commercial LED lighting market is projected to grow at a CAGR of 8.2% through 2028, with architects and project managers prioritizing products that balance performance, longevity, and compliance with local standards. In this context, lighting solutions must not only deliver superior illumination but also align with regional regulatory frameworks to ensure seamless deployment across international markets.

Why Certification Compliance is Non-Negotiable for Importers

For global lighting distributors and contractors, product certifications are not merely checkboxes—they are critical gatekeepers for market access. In North America, ETL certification (equivalent to UL) ensures compliance with electrical safety standards under OSHA and NEC requirements. Similarly, the TUV CE mark in Europe verifies adherence to the Low Voltage Directive (LVD) and EMC Directive, which are mandatory for sale in the EU. Without these certifications, imported products face significant risks: customs delays, costly rework, or outright rejection. Moreover, non-compliant products can expose importers to liability issues in the event of safety incidents. Leading manufacturers like Beauty STC Lighting address these challenges by embedding compliance into their design and production processes from the outset, ensuring that every product meets the exacting standards of Western markets.

Beauty STC Lighting: Engineering Excellence Since 1998

Established in 1998, Beauty STC Lighting has spent over 25 years refining its manufacturing processes to deliver reliable, certified LED solutions for global markets. As a factory-direct supplier with full ETL (USA/Canada) and TUV CE (Europe) certifications, we specialize in OEM/ODM services tailored to the specific needs of commercial, industrial, and architectural projects. Our commitment to quality is embedded in every stage of production, from raw material sourcing to final testing, ensuring consistent performance and compliance with international standards.

Product Category	Certifications	Key Technical Specifications
Flexible LED Strip Light	ETL (USA/Canada), TUV CE (Europe)	IP65 rated, 120-180 lm/W efficacy, CRI >90, 2700K-6500K CCT, customizable lengths up to 100m
LED Panel Light	ETL, TUV CE	12mm slim profile, 100-120 lm/W, flicker-free operation, 5-year warranty, 3000K-6000K CCT
LED Floodlight	ETL, TUV CE	IP66 rating, 150 lm/W efficacy, 120° beam angle, -40°C to +50°C operating range
LED UFO High Bay	ETL, TUV CE	150-180 lm/W, IP65, 50,000h L70 lifespan, 2700K-6500K CCT
LED T8/T5 Tubes	ETL, TUV CE	T8: 16W/4ft, T5: 14W/5ft, 120-140 lm/W, ballast compatible or direct wire options

Our OEM/ODM capabilities enable clients to customize product specifications, packaging, and branding to meet unique project requirements. With a dedicated engineering team and full in-house production capabilities, we ensure seamless integration of client specifications while maintaining strict adherence to certification standards. This approach has enabled us to serve over 50 countries worldwide, including key markets in Europe, North America, and Asia-Pacific.

Guided by principles of responsibility and innovation, Beauty STC Lighting combines technical expertise with sustainable manufacturing practices to support the long-term success of our partners.

---

Contact:
Manager: [email protected]
Phone: +86 13902885704
Address: 41st, Caihong Road, High-tech Industrial Zone, Jianghai District, Jiangmen City, Guangdong, China

---

Technical Specs & Certifications (ETL/CE)

Technical Specifications & Quality Standards

Why “White” is Never Just White in Industrial LED Lighting

At Beauty (STC) Manufacturing Co., Ltd—operating since 1998 and shipping ETL/TUV-CE listed products to 50-plus countries—we treat white light as a measurable engineering variable, not a marketing adjective.
Below is the factory-direct data our OEM/ODM clients request before they commit PCB space, luminaire housing, or project spec sheets.

---

1. Key Photometric & Electrical Targets

Parameter (Typ. 24 VDC Strip)	Beauty STC Certified Range	Generic Market Range	Test Standard / Notes
Luminous Efficacy	160–200 lm/W @ 3000 K	90–130 lm/W	Integrating sphere, IES LM-79-19
CRI (Ra)	≥ 90 (R9 > 50)	70–80	CIE 13.3, TM-30-20
SDCM (MacAdam Ellipse)	≤ 3-step	5–7-step	ANSI C78.377
L70 Lifetime	54 000 h @ 45 °C Ta	25 000–35 000 h	IES TM-21-19 calculator
Flicker Percent	< 5 % (IEEE 1789)	15–30 %	Oscilloscope 1 kHz
Binning Voltage	± 0.2 V per reel	± 0.5 V	In-house 100 % burn-in

---

2. Mechanical & Environmental Integrity

Attribute	Beauty STC Build	Common Alternative	Verification
PCB Copper Wt.	2 oz (70 µm) double-layer	1 oz (35 µm) single-layer	IPC-6012D
LED Pitch	4.8 mm (240 LEDs/m)	5–8 mm	Auto-optical alignment
IP Rating Options	IP20, IP54 Silicone sleeve, IP67 Nano-coating, IP68 Full extrusion	Usually IP20 only	IEC 60598-1
Operating Temp.	–40 °C … +85 °C	–20 °C … +60 °C	Thermal chamber 4 h
Flame Class	UL 94 V-0 PCB & housing	HB or no data	ETL witness test

---

3. Process Controls That Guarantee Reel-to-Reel Consistency

1. Single-Bin LED Procurement
   We lock 1/9th chromaticity bin from Lumileds or Seoul Semiconductor for every PO, eliminating visible color drift across 5 000 m batches.

2. Solder-Print & Reflow under Nitrogen
   5-zone Heller 1809 MKIII with O₂ < 50 ppm; reduces voiding to < 5 % (X-ray sample 5 pcs/200 m).

3. 100 % AOI + 2 h 75 °C Burn-In
   Any forward-voltage outlier (> ±0.1 V) triggers automatic reel rejection.

4. Integrating-Sphere Sampling Rate
   3 lm/W and 2 CRI points every 50 m; data logged and shipped with each carton for traceability.

5. Dual-Certified Safety/EMC Files
   ETL 5004870 (US/Canada) and TUV CE 50222982 (EU) remain valid under our annual Factory Production Control audits—no re-testing cost to OEM partners.

---

4. Quick-Scan Spec Table for Distributor Cut-Sheets

Order Code	CCT	CRI	lm/m	W/m	Efficacy	IP	Reel Length
BSTC-24V-30-90-IP20	3000 K	92	4800	24	200 lm/W	IP20	5 m
BSTC-24V-40-90-IP67	4000 K	93	5000	26	192 lm/W	IP67	5 m
BSTC-24V-57-90-IP68	5700 K	90	5200	28	186 lm/W	IP68	5 m

All figures are Tc = 45 °C, per IES LM-79-19, 1 m sample.

---

5. Application Guidance for Specifiers

Architectural Cove & Millwork: Use IP20, 160° dome lens, 3-step SDCM for seamless wall washing.
Retail Fridge & Shelf: Specify IP54 silicone sleeve; CRI ≥ 90 preserves produce chroma.
Exterior Façade Pixel-Free Line: IP68 extrusion with –40 °C cold-start; pair with 48 V driver to limit current drop < 5 % over 15 m runs.

---

6. Takeaway for Procurement & Design Teams

When you list a white-light LED assembly in a schedule, you are implicitly signing off on efficacy, color stability, and PCB thermal performance for a decade.
Beauty STC’s 25-year, factory-direct record—and ETL/TUV-CE files that transfer royalty-free to your OEM brand—remove the uncertainty normally hidden behind “marketing lumens.”

For project-specific .IES, .LDT, or UL data sheets, email [email protected] or call +86-13902885704 (GMT+8).

---

Factory Tour: Manufacturing Excellence

Manufacturing Excellence: Precision Engineering for Global Standards

At Beauty STC Lighting, our Jiangmen facility—established in 1998—integrates advanced manufacturing technology with rigorous quality protocols to deliver certified, high-performance lighting solutions for global markets. As a certified OEM/ODM partner for distributors, architects, and project managers, we prioritize technical precision, regulatory compliance, and scalability across all production stages.

Advanced Production Line Technology

Our 15,000m² facility in Jiangmen High-tech Industrial Zone features fully automated, ISO-compliant assembly lines engineered for consistency and efficiency:
High-precision SMT assembly: Juki FX-100A placement systems with ±0.03mm accuracy and automated optical inspection (AOI) for defect detection at component level.
Advanced soldering processes: Wave soldering and reflow ovens compliant with IPC-A-610 Class 2 standards for reliable electrical connections.
Encapsulation and housing: Climate-controlled stations ensuring consistent sealing for IP-rated products (IP20–IP67).
Automated testing stations: Real-time voltage/current monitoring during critical assembly phases to prevent early-stage failures.

This integrated approach minimizes human error while maintaining throughput for orders of 500–50,000+ units per month.

Rigorous Quality Assurance Protocols

Every product undergoes multi-stage validation aligned with ETL (USA/Canada) and TUV CE (Europe) certification requirements:

Quality Check Stage	Process	Standards Compliance
Incoming Material Inspection	Raw components (LED chips, PCBs, drivers) tested for electrical and mechanical integrity	IEC 62612, IEC 62717
In-Process Testing	Functional checks at each assembly stage (e.g., solder joint integrity, driver compatibility)	IPC-A-610 Class 2
48-Hour Aging Test	Continuous operation at 40°C ambient temperature with real-time monitoring of voltage, current, and lumen output	IEC 60598-1 (Luminaires Safety)
Final Inspection	Lumen output verification, color consistency (Δu’v’ < 0.003), IP rating validation, and safety compliance checks	ETL/CE certification protocols

These protocols ensure 99.8% first-pass yield rates and eliminate field failures for critical infrastructure projects.

OEM/ODM Capabilities Tailored to Project Needs

We provide end-to-end customization for global clients, from conceptual design to certified production. Our engineering team collaborates directly with architects and distributors to optimize specifications while maintaining compliance with regional standards:

Parameter	Options	Compliance Notes
LED Strip Length	1m–100m continuous with user-defined cut points	Custom cut points validated per IEC 60598
CCT (Correlated Color Temperature)	2700K–6500K (including tunable white)	±50K tolerance per ANSI C78.377
Dimming Protocols	0-10V, DALI, PWM, Triac	ETL-certified for North American markets
IP Ratings	IP20 (indoor), IP65 (outdoor), IP67 (submersible)	Validated through IEC 60529 testing
Packaging	Private labeling, retail-ready displays, bulk shipping	Compliant with destination country regulations (e.g., EU WEEE, US EPA)

For specialized requirements—including custom PCB layouts, thermal management solutions, or unique form factors—our R&D team provides full design support with rapid prototyping (7–10 days) and DFMA (Design for Manufacturing and Assembly) optimization.

---

With 25+ years of experience manufacturing certified lighting solutions for 50+ countries, Beauty STC Lighting delivers reliable, specification-grade products engineered for global infrastructure projects. Our Jiangmen facility combines industrial-grade automation with stringent quality control to meet the exacting demands of commercial and architectural applications.

For technical specifications or project consultation, contact our engineering team:
[email protected] | +86 13902885704

---

Installation & Application Scenarios

H2 | Where LED White Lighting Adds Measurable Value

(Engineering notes from Beauty (STC) Mfg. Co., Ltd – ETL & TUV CE listed since 1998, ISO-9001 OEM/ODM factory)

---

H3 | Hospitality & Service Environments

Application Node	Recommended CCT & CRI	Beam Control	Installation Notes for Contractors
Lobby chandelier recess	3000 K, CRI ≥ 90, 2-step SDCM	120°/ft COB strip in aluminum channel	Use low-voltage (24 V) class-2 drivers, ETL-listed for 100–277 V. Mount channel on steel frame @ 300 mm centers to eliminate thermal sag.
Corridor wall wash	3000–3500 K, CRI 85	60° asymmetric lens	Continuous run ≤ 5 m per feed to limit V-drop < 3 %. Route T-joins through factory pre-soldered cables—no field soldering needed, keeps ETL warranty valid.
Guest-room cove	2700 K, CRI 90	140° flex PCB	Install on heat-sink profile ≥ 8 mm thickness; maintain 5 mm air gap to drywall for 50 000 h L70.

---

H3 | Retail & Shopping Malls

Application Node	Recommended CCT & CRI	Luminous Efficacy	Contractor Tips
Shelf highlight	4000 K, CRI 95	160 lm/W @ 400 mA	Use 10 mm pixel-pitch high-density strip (840 LEDs/m) for zero-dotting. Feed every 2.5 m; 20 AWG feeder sufficient for < 2 % drop.
Atrium pendant	3500 K, CRI 90	120 lm/W	Integrate 0–10 V linear driver inside pendant spine; keep T-case ≤ 65 °C for 50 000 h life. Driver must carry both ETL & CE CB scheme certificate.

---

H3 | Corporate Offices

Application Node	Recommended CCT & CRI	Unified Glare Rating (UGR)	Contractor Tips
Open-office troffer retrofit	4000 K, CRI 80	UGR < 19	Replace fluorescent with our T8 18 W Type-B (ballast bypass) tube; single-end power to meet UL 1598C. Verify existing socket is shunted; if not, replace with non-shunted lampholders.
Video-conference cove	3000–4000 K tunable, CRI 90	SDCM ≤ 3	Use dual-channel 24 V strip + DALI-2 driver; pair to occupancy & daylight sensors. Factory pre-addresses DALI gear to reduce commissioning time by 30 %.

---

H3 | Façade & Landscape

Application Node	Recommended CCT & IP Rating	Surge Protection	Contractor Tips
Brick uplight	4000 K, IP67, IK08	6 kV/3 kA	Use 24 V constant-voltage flood, 1 W/100 mm, mounted on stainless bracket 300 mm from wall. Route rubber-insulated cable through IP68 junction boxes; keep driver indoors for 50 000 h life.
Crown-mouth strip	3000 K, IP65	2 kV line-line	Extruded silicone neon-flex, 8 × 16 mm profile, 180° viewing. Clip every 250 mm; allow 5 mm thermal expansion gap at –20 °C to +45 °C swing.

---

H3 | Installation Checklist (Factory-Direct Protocol)

1. Certifications on Site
   Demand ETL/CSA report #3015989 and TUV CE EN 60598-2-20 paperwork for every batch—keeps inspector sign-off under 15 min.
2. Thermal Path
   Minimum 4 in² of aluminum per watt for strip; 20 in² for flood. Our extrusions exceed this; if you substitute, verify ΔT junction-ambient < 25 K.
3. Voltage Drop Math
   24 V system: 5 m load, 4.8 W/m → 2.5 mm² (13 AWG) feed limits drop to 2.8 %. Use our online calculator (OEM login) for custom runs.
4. Surge & ESD
   Outdoor lines: add 20 kA SPD on 277 V panel; secondary 6 kV on driver input. Beauty STC drivers already integrate 4 kV; field SPD brings it to local code (IEEE C62.41).
5. Tool-Free Wiring
   Lever-style terminal blocks on all OEM strips—reduces install time 40 % vs. screw type and eliminates strand cutting that voids ETL.

---

H3 | Supply Chain Note for Distributors

MOQ: 500 m per CCT for custom binning (< 3 SDCM).
Lead-time: 18 days ex-factory Jiangmen, including ETL witness test if required.
Packaging: 5 m reels, anti-static aluminium foil, 50 reels per carton, 9 kg net—optimised for 1 CBM mixed shipment to EU & NA.

For project submittals or OEM drawings, contact:
[email protected] | +86-13902885704

---

Why Choose Beauty STC Lighting

Partner with Beauty STC Lighting: Engineering Excellence for Global Projects

Global Compliance & Certification Assurance

Our products undergo rigorous testing to meet international safety and performance standards, ensuring seamless integration into projects worldwide:

Certification	Target Markets	Compliance Standards
ETL	United States, Canada	UL 1598, CSA C22.2 No. 250.0
TUV CE	European Union	EN 60598-1, EN 62368-1

25+ Years of Manufacturing Expertise

Founded in 1998, Beauty STC Lighting has established itself as a reliable partner for global lighting projects through consistent quality control, sustainable manufacturing practices, and technical innovation. Our Jiangmen-based facility combines decades of industry experience with modern production methodologies to deliver precision-engineered solutions for demanding commercial and architectural applications.

Tailored OEM/ODM Solutions for Architectural and Commercial Projects

We collaborate directly with architects, contractors, and project managers to develop customized lighting systems that align with specific design, performance, and regulatory requirements. From concept development and prototyping to compliance testing and mass production, our engineering team provides end-to-end support for:
Custom color temperatures and CRI optimization
Specialized form factors and mounting configurations
Smart lighting integration and IoT-compatible controls
Region-specific compliance validation

Partner with Us

With successful exports to 50+ countries across Europe, North America, Southeast Asia, Australia, Russia, Japan, and Korea, Beauty STC Lighting delivers certified, high-performance solutions engineered for global markets. For project-specific technical specifications, custom solution proposals, or collaboration inquiries:
[email protected] | 0086-13902885704

---
