The Growing Demand for Industrial Infrared LED Solutions

Key Applications Driving Market Growth

Infrared (IR) LED technology has become a critical enabler across industrial and commercial applications where visible light is impractical or undesirable. Security systems rely on consistent IR illumination for 24/7 surveillance in low-light conditions, while machine vision applications demand precise wavelength control for accurate object detection and quality control. Agricultural monitoring systems utilize IR for plant health analysis, and industrial automation requires robust components that withstand extreme temperatures, vibration, and continuous operation. These use cases demand IR LEDs with strict adherence to electrical safety, thermal management, and optical consistency standards.

Why Quality and Compliance Matter for Importers

For global distributors and project managers, regulatory compliance is non-negotiable. ETL certification ensures products meet North American safety standards (UL/CSA), while TUV CE certification validates compliance with European Union directives. Non-compliant components risk customs delays, costly recalls, and reputational damage. Additionally, uncertified IR LEDs often suffer from inconsistent radiant flux, premature failure, or electromagnetic interference—critical flaws in industrial environments where downtime is costly. Beauty STC Lighting’s dual certification demonstrates a commitment to quality that directly addresses these concerns, ensuring seamless market entry and long-term reliability.

Introducing Beauty STC Lighting: A Trusted Partner for Industrial IR LED Solutions

With over 25 years of manufacturing excellence since 1998, Beauty STC Lighting specializes in high-reliability LED solutions tailored for industrial applications. Our facility in Jiangmen, China, is equipped to produce ETL and TUV CE-certified infrared LEDs that meet the rigorous demands of global markets. We offer comprehensive OEM/ODM services, enabling clients to customize specifications for wavelength, power output, and form factor to suit specific project requirements.

Parameter	Specification
Wavelength Range	750nm – 950nm (customizable)
Radiant Flux	100mW – 500mW per LED
Operating Temperature	-40°C to +85°C
Certifications	ETL (USA/Canada), TUV CE (Europe)
Lifespan	50,000+ hours (L70)
Customization	OEM/ODM available for wavelength, optics, packaging

Contact us today to discuss your project requirements:
[email protected] | +86 13902885704

---

Technical Specs & Certifications (ETL/CE)

Technical Specifications & Quality Standards for Beauty STC Infrared LEDs

1. Spectral & Electrical Benchmarks (λ = 760 nm … 940 nm)

Parameter	Test Condition	Beauty STC Binning Limit	Industry “7-segment” Range
Peak Wavelength tolerance	25 °C, IF = 350 mA	± 5 nm	± 15 nm
Radiant Flux (850 nm chip)	25 °C, IF = 700 mA	850 mW min.	500–1200 mW (loose bin)
Forward Voltage	25 °C, IF = 350 mA	1.45–1.65 V	1.3–1.9 V
Wall-plug Efficiency	25 °C, IF = 700 mA	≥ 42 %	30–45 %
Thermal Resistance, junction-solder point	JEDEC 51-14	5.5 °C/W typ.	6–10 °C/W
ESD withstand	Human-body model	8 kV	2–4 kV

All measurements performed on an integrated 38 cm integrating sphere calibrated to NIST traceable standards in our Jiangmen reliability lab.

---

2. Mechanical & Environmental Ratings

Feature	Beauty STC Build	Generic Market Option
Ingress Protection	IP67 (strip) / IP68 (flood module)	IP44–IP65
PCB Base	Double-layer 2 oz copper, 3 000 V dielectric; thermally conductive adhesive (TC ≥ 1.2 W/m·K)	1 oz, FR-4, no thermal adhesive
Solder Mask	White high-reflectance IR-transparent; ≥ 92 % reflectivity @ 850 nm	Standard green mask, 60 % reflectivity
Operating Temperature	−40 °C … +85 °C	−20 °C … +60 °C
Lifetime to L70	50 000 h @ 85 °C Tj	25 000–30 000 h @ 25 °C ambient
Automotive Shock/Vibe	10 g, 10–2 000 Hz, 8 h/axis (AEC-Q102 inspired)	Not specified

---

3. Certification & Traceability Matrix

Certification Body	Scope	Beauty STC Status	Certificate ID
ETL (Intertek)	UL 8750, CSA C22.2 #250.13	Listed	5012232
TÜV SÜD	EN 62471 (photobiological), EN 62031, CE-LVD & CE-EMC	Listed	44 78 14812 001
RoHS / REACH	2011/65/EU + (EU)2015/863	< 0.1 % each restricted substance	Internal report BEA-RoHS-24
ISO 9001:2015	Design, manufacture, sales	Valid until 2026	01 100 041382

Full C of C & PPAP level-2 paperwork available for OEM/ODM partners.

---

4. Consistency Controls Implemented Since 1998

Die-sorting: Every IR chip is wavelength-binned at the wafer level; automatic pick-and-place rejects ±3 nm outliers.
Reflow profile validation: 10-zone Heller oven with real-time KIC profiler; solder-joint voiding < 5 % by X-ray.
Thermal cycling: −40 ↔ +125 °C, 500 cycles, 30 min dwell; ΔVF < 0.05 V pass criterion.
LM-80 style test: 6 000 h on-stream at 55 °C/85 °C/105 °C Tj; data filed for Energy-Star customer projects.
Traceability: 2-D code on each aluminium PCB links to MES batch (min. retention 10 years).

---

5. Quick-Reference Table: Generic Market Quality vs. Beauty STC Certified Quality

Attribute	Typical “Web-shop” IR Module	Beauty STC Certified Build
Wavelength accuracy	± 15 nm (mixed reels)	± 5 nm, single-bin reels only
Radiant maintenance @ 5 kh	70 %	85 % (L85)
PCB copper weight	1 oz	2 oz + thermal adhesive
IP rating	IP44–IP65	IP67 (strip) / IP68 (flood)
Safety marks	self-declared CE	ETL + TÜV CE, test reports on file
OEM support	MOQ 10 k, no PPAP	MOQ 500 m (strip) or 100 pcs (flood), full PPAP & CB reports
Factory experience	< 5 years IR	25+ years LED, 12 years high-power IR

---

6. Available Platforms (factory-direct)

Flexible IR Strip: 2835/5050 SMD, 30–120 LEDs/m, 750/850/940 nm, 12/24 V, IP67 silicone sleeve.
IR Flood Light: 10–300 W, die-cast aluminium, 4 mm tempered glass, U-bracket, 8°/30°/60°/90° lens options.
High-bay IR Module: 100–800 W, hook or pendant, 50 000 mW/sr @ 850 nm, fan-less design −40 … +85 °C.

Custom PCB length, wavelength split, or integrated NTC/photo-diode available on request. Engineering samples ship from Jiangmen within 7 days.

For datasheets, IES files or to schedule a remote beam-pattern demonstration, contact:
[email protected] | +86-13902885704

---

Factory Tour: Manufacturing Excellence

Manufacturing Process & OEM Services

Beauty STC Lighting leverages 25+ years of LED manufacturing expertise since our establishment in 1998 to deliver precision-engineered infrared LED solutions. Our Jiangmen facility operates under strict quality protocols aligned with ETL and TÜV CE certifications, ensuring global market compliance for industrial and commercial applications.

Precision Manufacturing at Our Jiangmen Facility

Our production line in Jiangmen High-tech Industrial Zone features fully automated SMT assembly with Yamaha placement machines and reflow ovens featuring precise temperature profiling. This infrastructure supports microchip handling down to 0201 size, critical for high-density infrared LED arrays. Each stage of the manufacturing process—including substrate preparation, chip bonding, encapsulation, and wire bonding—is monitored through automated optical inspection (AOI) systems to maintain sub-micron tolerances. All production follows RoHS-compliant material standards and is conducted in climate-controlled environments to eliminate humidity-related defects.

Rigorous Quality Assurance Protocols

All IR LED products undergo comprehensive testing protocols to ensure reliability and performance consistency:
Aging Tests: 1,000-hour continuous operation at 60°C ambient temperature to validate L70 lifespan metrics.
Spectral Analysis: Wavelength accuracy verified using calibrated spectroradiometers with ±3nm tolerance.
Thermal Performance: Thermal imaging and thermal resistance testing per IEC 62717 standards.
Electrical Safety: Compliance checks for ETL/CE certifications including dielectric strength and leakage current tests.

These protocols align with IEC 62471 photobiological safety standards and ensure all products meet global regulatory requirements.

Custom OEM/ODM Capabilities

Beauty STC offers end-to-end OEM/ODM services tailored to project-specific requirements. Our flexible manufacturing system supports customization across key parameters while maintaining certified quality standards:

Parameter	Customization Options	Typical Applications
Wavelength	750nm, 850nm, 940nm, 1050nm	Surveillance, Machine Vision, Biometric Sensors
Power Output	0.5W–10W per chip, adjustable drive current	Industrial Heating, Medical Devices
Form Factor	Flexible strips (1–50m), SMD modules, COB arrays	Embedded Systems, Automotive Lighting
Packaging	7″ or 10″ reels, bulk trays, custom branding	Mass Production, Prototyping
Certifications	ETL, CE, RoHS compliant; automotive-grade options available	Global Market Compliance

Our engineering team collaborates closely with clients during the design phase to optimize thermal management, optical output, and mechanical integration. From prototype validation to full-scale production, we maintain full traceability through our quality management system.

For technical specifications or project-specific inquiries, contact our engineering team at [email protected] or +86 139 0288 5704.

---

Installation & Application Scenarios

H2 Where Spec-Grade Infrared LEDs Add Value in Commercial & Hospitality Projects

H3 1. No-Disruption Surveillance in 24-Hour Hotels & Resorts

Application driver: Star-rated properties must maintain CCTV performance when decorative lighting is dimmed or RGB scenes are active.
IR wavelength: 850 nm (semi-covert) or 940 nm (fully covert) to eliminate guest complaints about red-glow.
Mounting tip for contractors:
– Install 1 m offset from visible down-lights to avoid lens flare; use the same 0-10 V / DALI circuit so IR bars switch in parallel with “night scene”.
– Verify camera sensitivity curve; most Sony STARVIS sensors peak at 850 nm.
Beauty STC factory-direct option: 300 W IP66 bar, 50 000 h L70, ETL & TUV CE file #5016237—shipped with swivel trunnion and 1 m AWG16 whip for North-American junction-box spacing.

Specification	850 nm Version	940 nm Version
Radiant power	3 600 mW @ 700 mA	2 800 mW @ 700 mA
Half-angle	120°	120°
Operating temp	–40 °C – +85 °C	–40 °C – +85 °C
Certifications	ETL / CE / RoHS	ETL / CE / RoHS

H3 2. Retail Mall & Luxury Boutique – Covert Loss-Prevention

Use-case: High-end cosmetics aisle with 300 lx warm-white track; conventional IR spots create visible red dots on glossy packaging.
Solution: Integrate 940 nm COB IR strip inside aluminium profile directly behind the shelf lip; beam angle 30° x 60° elliptical to match camera field.
Installation note: Feed 24 VDC from the same UPS string that powers PoE cameras—no extra driver; maintain < 5 % ripple to prevent banding on 50 Hz CMOS.

H3 3. Smart-Office Occupancy & Meeting-Room Analytics

Trend: Post-COVID HVAC demand-controlled ventilation uses IR-based people-counting cameras (depth map).
IR requirement: Uniform 0.3 W m⁻² @ 850 nm, no hotspots > 0.8 W m⁻² (IEC 62471 exempt class).
Contractor checklist:
– Mount 2.7 m high, 1.5 m spacing, 30° tilt; use laser-level to guarantee ±10 % irradiance uniformity.
– Specify flicker-free driver (≤ 5 % @ 2 kHz) to avoid interference with ToF sensors.
OEM value-add from Beauty STC (est. 1998): 24 V flexible IR strip, 10 mm width, 5 W m, cuttable every 50 mm—supplied in 5 m reels with EN 60598-2-20 test report for Europe, ETL 153 standard for USA.

H3 4. Façade & Perimeter – IR Flood for ANPR / LPR Cameras

Challenge: License-plate recognition at 30 m with head-light glare.
IR LED flood: 750 nm high-power (8 W optical) in narrow 8° lens; plates retro-reflect > 40 % @ 750 nm, doubling image contrast.
Electrical tip: Run on 48 VDC to limit cable copper; use Myers hubs on junction box for IP66 seal—matches our ETL-listed 48 V driver, class 2 output.

Parameter	Unit	Value
Peak wavelength	nm	750 ± 10
Radiant flux	W	8 typ.
Forward voltage	V	14.5 (chip-on-board)
ESD	kV	2 (HBM, AEC-Q102)
Lifetime L70	h	50 000 @ 85 °C Tj

H3 5. Healthcare & Assisted Living – Non-Intrusive Night Monitoring

Need: Maintain melatonin rhythm—zero visible light.
IR source: 940 nm edge-lit panel, 600 mm x 600 mm, recessed into corridor ceiling; 0.2 W m⁻² on floor meets IEC 62471 exempt.
Certification reminder: Specify UL 94 V-0 diffuser and TP(a) rating for healthcare plenum—Beauty STC can laser-etch OEM logo & part-code for asset tracking.

---

H2 Field Installation Quick-Reference (Contractors)

1. Voltage drop: For 24 V strips > 5 m, loop feed both ends or use 2.5 mm² cable to keep ΔV < 5 %.
2. Thermal: Allow 50 mm free-air clearance on IP66 bars; T-case ≤ 85 °C per ETL report.
3. Glare shield: Use supplied black-anodised glare louvre when IR emitter is within 15° of camera axis.
4. Grounding: Earth tab on every third metre—required for CE surge 1 kV L-N, ETL 6 kV ring-wave.
5. Documentation: Beauty STC ships each batch with LM-80 snapshot, Zhaga book-13 stencil, and dual-language installation sheet—keeps local inspector timelines short.

Contact our application engineering team ([email protected], +86-13902885704) for custom wavelength bins, private-label packaging, or project-specific IES files.

---

Why Choose Beauty STC Lighting

Partner with Beauty STC Lighting for Industrial Infrared LED Solutions

Precision Infrared LED Manufacturing for Global Projects

Infrared (IR) LEDs are critical for industrial applications including machine vision, surveillance systems, industrial sensing, and medical diagnostics. As a manufacturer with 25+ years of experience, Beauty STC Lighting delivers certified, high-reliability IR LED solutions engineered to meet stringent global standards. Our facility in Jiangmen, Guangdong, operates under ISO-aligned quality control protocols, ensuring consistent performance for demanding industrial environments.

Technical Specifications & Customization Capabilities

Our OEM/ODM services support precise alignment with project-specific technical requirements. Below are standard specifications for our IR LED product range, with full customization available:

Parameter	Standard Range	Custom Options
Wavelength	750nm, 850nm, 940nm	700–1500nm (tailored to application)
Power Output	0.5W–5W per emitter	Up to 10W (with thermal management)
Lifespan	>50,000 hours (L70)	Extended lifespan configurations
Certifications	ETL, TUV CE, RoHS	Project-specific compliance
Thermal Resistance	≤10°C/W	Custom heat sink integration
Packaging	SMD, COB, TO-Can	Multi-chip configurations

All products undergo rigorous thermal, optical, and electrical validation to ensure stability in high-stress environments.

Certified for Global Markets

Beauty STC Lighting holds ETL certification (USA/Canada) and TUV CE certification (Europe), validating compliance with North American and European safety, performance, and environmental standards. These certifications are critical for distributors and contractors working on international projects requiring traceable quality assurance. Our products have been successfully exported to 50+ countries, including stringent markets in Europe, North America, and Japan, with consistent adherence to regional regulatory frameworks.

25+ Years of Engineering Excellence

Established in 1998, our manufacturing expertise spans the evolution of LED technology from early-stage development to modern industrial applications. We maintain full control over the supply chain—from raw material sourcing to final testing—ensuring reliability and cost efficiency. Our engineering team collaborates directly with clients to optimize IR LED designs for:
Industrial automation and machine vision systems
Security and surveillance infrastructure
Medical and healthcare diagnostic equipment
Automotive and transportation sensing applications

All products are manufactured in our Jiangmen facility under strict process controls, with traceability maintained through every production stage.

Partner with Us for Your Next Project

For projects requiring certified, high-reliability infrared LED solutions, contact Beauty STC Lighting to discuss your OEM requirements. Our team provides technical documentation, sample validation, and end-to-end support for global procurement needs.
