Industry Insight: Colour Led Lamp
Meeting Commercial Lighting Demands with Certified Colour LED Solutions
In today’s commercial and industrial landscapes, colour LED lighting solutions are no longer optional—they’re fundamental to energy efficiency, design flexibility, and human-centric environments. From retail accent lighting requiring precise colour rendering to industrial spaces needing dynamic tunable white systems, project success hinges on reliable, compliant products. However, global procurement introduces significant challenges: regional electrical standards, safety regulations, and environmental compliance must be met without compromise. For importers and project stakeholders, certification is not a formality but a critical risk-mitigation tool.
The Critical Role of Quality Certification in Global Lighting Procurement
Certifications like ETL (USA/Canada) and TUV CE (Europe) are non-negotiable for market access and operational safety. These marks validate that products have undergone rigorous third-party testing against standards such as UL 1598 (luminaires), IEC 60598 (lighting equipment), and EU RoHS (hazardous substances). Without these certifications, projects face:
Customs delays or rejections at international borders
Liability risks from electrical safety failures
Reputational damage from non-compliant installations
Voided warranties and insurance claims
Beauty STC Lighting addresses these risks head-on. Every product in our portfolio undergoes certified testing prior to shipment, ensuring seamless compliance for North American, European, and other regulated markets.
Why Beauty STC Lighting is the Trusted Partner for Commercial Projects
Since 1998, Beauty STC has manufactured lighting solutions for global markets, with 25+ years of experience navigating complex regulatory environments. Our ETL and TUV CE certifications for all core products ensure seamless integration into Western projects. As an OEM/ODM specialist, we tailor lighting solutions to exact specifications while maintaining rigorous quality control.
Technical Specifications & Compliance Framework
| Product Category | Certifications | Key Technical Attributes |
|---|---|---|
| Flexible LED Strip Lights | ETL (US/Canada), TUV CE (EU) | RGB/RGBW/tunable white options; CRI >90; IP20-IP68 ratings; 24V/48V options; 16.4ft-164ft lengths |
| LED Panel Lights | ETL, CE | 3000K-6000K tunable white; dimmable; flicker-free; Energy Star & DLC Premium compliant |
| LED UFO High Bay | ETL, CE | 150W-300W; 130+ lm/W efficacy; IP65 rating; IK10 impact resistance; 120° beam angle |
| T8/T5 LED Tubes | ETL, CE | Direct wire/dual-ended; 25,000+ hours lifespan; RoHS compliant; 120-150 lm/W efficiency |
Engineering Excellence for Global Standards
Our manufacturing process integrates in-house testing protocols aligned with IEC 60598, IEC 62471, and ANSI standards. Thermal management systems are validated through accelerated life testing, while optical performance is measured using goniophotometers. Each batch undergoes electrical safety checks per IEC 61010-1 before certification. This engineering rigor ensures consistent quality across all orders, whether standard catalog items or fully custom OEM solutions.
As a factory-direct manufacturer with a quarter-century of experience, Beauty STC Lighting delivers colour LED solutions engineered for global compliance and performance. Partner with us to eliminate certification risks and accelerate your project timelines.
Contact:
[email protected] | +86 139 0288 5704
41st, Caihong Road, High-tech Industrial Zone, Jianghai District, Jiangmen City, Guangdong, China
Technical Specs & Certifications (ETL/CE)
Technical Specifications & Quality Standards
Colour LED Lamp – Factory-Certified Performance for Specification-Grade Projects
1. Key Photometric & Electrical Metrics
| Parameter | Beauty STC Certified Range | Notes for Distributors & Specifiers |
|---|---|---|
| Luminous Efficacy | 110–140 lm/W (single-colour) / 95–115 lm/W (RGBW) | 24 h LM-80 data @ Tj 85 °C, 3 SDCM |
| CRI | Ra ≥ 90 typ. (2700–4000 K) / Ra ≥ 85 (R,G,B ch.) | R9 > 50; complies with TM-30-18 |
| L70 Lifetime | 54 000 h (Ta 45 °C) | Per IESNA TM-21-19, 6 000 h data set |
| Chromaticity | 3-step MacAdam ellipse | Δuv ≤ 0.003, batch-to-batch |
| Flicker | <1 % @ 100 Hz | IEEE 1789-2015 “no-risk” zone |
| Input | 24 VDC constant-voltage / 48 VDC CC optional | SELV, class II, <60 VDC for EU |
| Power Factor | ≥ 0.95 (driver inclusive) | Meets ErP 1194/2012 & DOE Level VI |
| Stand-by | <0.2 W | ErP 1275/2008 |
| Ambient | –40 °C … +55 °C | 5 %–95 % RH non-condensing |
| IP Rating | IP20 (indoor) / IP65 (silicone sleeve) / IP67 (PU tube) | IK06 on AL profile variants |
| PCB | 2 oz (70 µm) ED copper, 1.6 mm FR-4, 150 °C TG, UL 94 V-0 | 5 mm² pads for C4 soldering |
| Certifications | ETL cETL (UL 2108 & CSA 250.13) / TUV CE (EN 60598-2-22, EN 62031) | CB, SAA, RoHS, REACH, ERP |
2. Consistency & Traceability Controls
Beauty STC Lighting, in continuous production since 1998, runs a 7-stage QC protocol on every colour LED lamp lot:
- Incoming Chip Binning – Partnered with Lumileds & Seoul Semiconductors; colour, flux and Vf bin-locked per reel.
- Solder Paste Inspection (SPI) – 3-D paste volume check, ±15 % tolerance.
- Automotive-grade Mounter – Yamaha YSM-20R, ±35 µm placement.
- Reflow & AOI – 10-zone convection, AOI verifies solder joint void <5 %.
- IPQC Photometry – 100 % luminous flux & chromaticity on integrating sphere; data logged by reel ID.
- 48-h Burn-in – 45 °C, 75 % RH, on/off 30 s cycle; rejects <0.2 %.
- Package Audit – vacuum-sealed with desiccant & HIC, RoHS label, barcode for forward & reverse traceability.
3. Generic Market vs. Beauty STC Certified Quality
| Attribute | Typical Generic Supply | Beauty STC Certified Reel |
|---|---|---|
| Efficacy (lm/W) | 70–90 | 110–140 |
| CRI | 70–80 | ≥ 90 (2700–4000 K) |
| SDCM | 5–7 | ≤ 3 |
| Copper Weight | 1 oz (35 µm) | 2 oz (70 µm) |
| Thermal Conductivity | 1.0 W/m·K dielectric | 1.5 W/m·K, white solder mask |
| Bin Consistency | Mixed reels | Single bin per reel, barcode |
| Lifetime Claim | Un-supported | 54 k h TM-21, 6 k h data |
| Safety Mark | Self-declaration | ETL cETL + TUV CE, file listed |
| Regulatory | Partial | ErP, RoHS, REACH, WEEE, Prop-65 |
| Warranty | 1 year | 5 year limited, field <0.3 % |
| OEM Traceability | Manual | ERP lot ID, 10-year record |
4. Specification Guidance for Distributors / Contractors
CCT & Tolerance: Specify 3-step MacAdam + Δuv ≤ 0.003 to eliminate visible strip-to-strip colour drift on long runs.
IP Rating: Use IP65 silicone sleeve for damp coves; IP67 PU extrusion for façade outlines (–40 °C freeze-proof).
Powering: Limit run length to 5 m @ 24 V for <3 % V-drop; feed both ends on 10 m runs.
Controls: Pair with DMX512 or Casambi-ready drivers; constant-voltage design simplifies parallel wiring.
Mounting: Extruded 6063-T5 anodised profiles with 3 M VHB or #8 screws; thermal pad Rth <1 K/W.
5. OEM / ODM Capability
In-house SMT lines (8): 700 k pc/month capacity, 48 h prototype, 2-week bulk.
Custom CCT, CRI, SPD: Bin-preserve with Philips LUXEON 3030 HE or 2835 Color.
LOGO print, custom reel length (0.5–5 m), colour box, and driver pairing – all under one roof in Jiangmen, 41 Caihong Road.
Complete test dossier provided: IES, LDT, TM-21, ISTMT, SDS, DoC for EU/NA markets.
For project submittals or .dwg / .ies files, contact:
[email protected] | +86-13902885704
Factory Tour: Manufacturing Excellence
Manufacturing Excellence & Tailored OEM/ODM Solutions
With over 25 years of manufacturing expertise since 1998, Beauty STC Lighting operates from a purpose-built facility in Jiangmen’s High-tech Industrial Zone, integrating industrial-grade automation with rigorous engineering standards. Our production processes are designed to deliver consistent quality for global markets, with certifications and protocols validated by independent third-party auditors.
Precision Factory Infrastructure
Our Jiangmen facility, established in 1998 and situated within the Jianghai District High-tech Industrial Zone, features fully automated SMT (Surface Mount Technology) assembly lines capable of handling high-volume LED component placement with micron-level precision. Each production station is monitored through IoT-enabled quality control systems, ensuring real-time data collection and process consistency across all product lines. Key infrastructure includes:
Automated SMT Lines: For PCB assembly with 99.98% placement accuracy
Advanced Aging Test Chambers: Simulating 5+ years of operational stress under controlled thermal and humidity conditions
Precision Cutting & Bonding Stations: For flexible LED strips and custom luminaires
Rigorous Quality Control Protocols
Every product undergoes a multi-stage quality assurance process aligned with ETL (USA/Canada) and TÜV CE (Europe) certification requirements. This includes:
100% Visual Inspection: At critical assembly stages to detect soldering defects or component misalignment
Electrical Parameter Verification: Testing voltage, current, and lumen output against design specifications
Thermal Imaging Analysis: Identifying hotspots and ensuring thermal management compliance
IP Rating Validation: For outdoor-rated products (e.g., IP65/IP67 floodlights and strips) via standardized water/dust resistance tests
All finished goods are certified by ETL and TÜV for compliance with North American and European safety standards, ensuring seamless market entry for global clients.
Flexible OEM/ODM Customization
Beauty STC provides end-to-end OEM/ODM services tailored to regional market demands and project-specific requirements. Our engineering team collaborates directly with clients to optimize product designs for performance, cost-efficiency, and regulatory compliance. Key customization capabilities include:
| Parameter | Standard | Customizable |
|---|---|---|
| LED Strip Length | 1m, 5m reels | 0.1m increments up to 100m |
| CCT Range | 2700K–6500K | Specific values within range (e.g., 2700K, 4000K, 5700K) |
| CRI (Color Rendering Index) | ≥80 | ≥90 available |
| IP Rating | IP20, IP65, IP67 | Project-specific ratings (e.g., IP68 for submersible applications) |
| Packaging | Standard retail boxes | Branded, eco-friendly, or region-compliant packaging (e.g., EU-specific labeling) |
For other product categories—including LED panel lights, floodlights, and high-bay fixtures—similar customization options are available. Our team provides full engineering support for unique requirements such as dimming protocols, voltage adaptations, and regional safety certifications. All custom solutions undergo rigorous validation testing to ensure alignment with client specifications and global market standards.
Contact us to discuss your project-specific requirements: [email protected] | +86 13902885704
Installation & Application Scenarios
Application Scenarios for Colour LED Lamp Systems
Factory-direct guidance for distributors, specifiers & on-site contractors
H2 | Where Colour LED Lamps Deliver Measurable ROI
| Segment | Primary Function | Typical Burn Hours/Year | Key Compliance Driver | Beauty STC Module Used* |
|---|---|---|---|---|
| 4- & 5-Star Hotels | Brand-specific ambience & circadian guest comfort | 6 000 h | CE Low-Voltage + EMC, ETL 1598 wet-location | 24 V RGBW 60 led/m, 10 mm width, 5-in-1 SMD |
| High-End Retail & Shopping Malls | Dynamic façade & window display to boost footfall | 4 500 h | TUV CE, RoHS, REACH | 24 V addressable 30 led/m, 12 mm, 10 W/m @ 100 % white |
| Corporate Offices (HCL) | Tunable-white task lighting, 80-120 fc on desk | 2 800 h | EN 12464-1, flicker <1 % | 24 V CCT 120 led/m, 8 mm, 14 W/m, CRI >90 |
| Entertainment Venues / Bars | Colour-chase ceiling coves & bottle shelves | 3 000 h | ETL for 120 V feed-through | 12 V RGB 60 led/m, 5 mm ultra-narrow, IP54 silicone sleeve |
| Exterior Façades & Bridges | Pixel-mapping media mesh | 8 760 h (dusk-to-dawn) | CE, ETL wet-location, LM-79 | 24 V UCS1903 10 mm, 96 W/m, IK08, -40 °C to +55 °C |
Modules are shipped as bulk reels (5 m) or factory-spliced to OEM length; all above versions carry Beauty STC’s dual ETL & TUV CE files since 2003.
H2 | Contractor Installation Checklist
(Field notes compiled from 25-year export data & CE/ETL site audits)
H3 | 1. Voltage-Drop Budget
24 V system: inject power every 5 m for loads ≤ 10 W/m; every 2.5 m for ≥ 14 W/m.
12 V system: inject every 2.5 m regardless of load.
Use loop-feed method on runs > 10 m to keep colour consistency Δu’v’ < 0.003.
H3 | 2. Heat Path for Colour Stability
Anodised aluminium profile ≥ 1.2 mm wall, 20 cm²/m surface area.
Maintain TP (tape-to-profile) interface < 70 °C; above this, lumen/colour shift > 3 % per 1 000 h.
For façade IP67 neon flex, silicone extrusion itself acts as heat sink—still mount on metal edge to avoid 10 °C rise.
H3 | 3. Class-II vs Class-I Wiring
ETL 1598 Class-II strips may be used without earth on 120 V circuits (USA).
In EU, TUV CE mandates SELV ≤ 120 V dc; therefore 24 V is default for exposed touchable parts.
Always confirm local code: Germany requires < 60 V dc in public areas.
H3 | 4. Driver & Control Pairing
Constant-voltage driver, ripple < 3 %, overload 125 % for 1 h.
For DMX pixel mapping, use Beauty STC SD-300 decoder (8 × 24 V, 5 A/ch) with RDM feedback—reduces call-backs.
0-10 V tunable-white: match driver’s dimming curve to IEC 60929; minimum dim 0.5 % to avoid magenta shift at low end.
H3 | 5. Certifications Paper Trail
Every reel ships with ETL control number & TUV CE DoC; keep copies for final inspector.
For USA jobs, retain LM-79 & TM-21 data—utilities increasingly request for rebate sign-off.
RoHS & REACH SVHC list updated quarterly; archive version with project close-out docs (required by EU distributors).
H3 | 6. Typical Mounting Mistakes (Avoid)
| Issue | Root Cause | Fix |
|---|---|---|
| Colour shift after 6 months | Profile too small, 90 °C at LED junction | Upgrade to 15 × 25 mm profile, or lower current to 350 mA |
| DMX flicker on long runs | Star wiring, 100 m CAT5, no terminator | Use RS-485 repeater every 32 decoders, 120 Ω termination |
| Glue de-bond on façade | Surface not degreased, –20 °C install | Clean with IPA, pre-heat surface to +10 °C, use 3M VHB 5952 |
H2 | Quick Specification Reference (Most Ordered Colour SKU)
| Parameter | RGBW 24 V, 60 led/m | Tunable White 24 V, 120 led/m |
|---|---|---|
| LED Source | Epistar 5050 + 2835 | Luxeon 2835E, 2-step SDCM |
| Power | 14.4 W/m | 14 W/m |
| Luminous Flux | 960 lm/m (white channel) | 1 050 lm/m (4000 K) |
| Efficacy | 67 lm/W | 75 lm/W |
| Beam | 120 ° | 120 ° |
| IP Grade | IP20 (IP67 sleeve opt.) | IP20 (IP65 coating opt.) |
| Cert. | ETL cETL, TUV CE, RoHS, REACH | Same |
| Reel Length | 5 m | 5 m |
| Cut Segment | 100 mm | 50 mm |
| Operating | –25 °C to +45 °C | –30 °C to +50 °C |
| Lifetime (L70) | 50 000 h @ 25 °C | 54 000 h @ 25 °C |
H2 | Next Step for OEM / ODM Projects
Beauty STC’s 12 000 m² Jianghai factory (Est. 1998) runs six SMT lines, in-house积分球 & 2 m integrating sphere, and holds ETL & TUV CE witness-test authorisation. Provide your CIE chromaticity targets, DMX channel map, or length schedule; we deliver fully soldered, 100 % aged reels in 10–15 days.
Contact: [email protected] | +86-13902885704
Why Choose Beauty STC Lighting
Partner with Beauty STC Lighting – Your Trusted LED Manufacturing Partner
Decades of Industry Expertise
Established in 1998, Beauty STC Lighting has delivered reliable, high-performance LED lighting solutions for over 25 years. Our Jiangmen, Guangdong manufacturing facility operates under stringent quality control protocols, ensuring products meet global technical and safety standards. We prioritize sustainable practices and innovation, aligning with our core principles: “Be a responsible enterprise, Be a caring person” and “Passionate, and Innovation”.
Global Compliance & Certification
All products are certified for key international markets, eliminating compliance barriers for distributors and project teams:
| Certification | Region | Scope |
|---|---|---|
| ETL | USA & Canada | UL 1598, 1573, and 8750 compliance for safety and performance |
| TUV CE | European Union | EN 60598, EN 62471, and EMC directive compliance |
Comprehensive Product Portfolio
Designed for commercial, industrial, and architectural applications with precision-engineered specifications:
| Product Type | Key Specifications | Primary Applications |
|---|---|---|
| Flexible LED Strip Lights | IP20–IP67, 2700K–6500K, CRI >80, 120° beam angle | Cove lighting, signage, architectural detailing |
| LED Panel Lights | 30W–60W, 4000K–5000K, CRI >90, 120° uniformity | Offices, retail spaces, healthcare facilities |
| LED Floodlights | 100W–500W, 4000K–5000K, IP66, 120°–150° beam | Warehouse security, sports arenas, outdoor safety |
| LED UFO High Bay | 150W–300W, 4000K–5000K, IP65, 120°–150° | Industrial warehouses, manufacturing plants |
| LED T8/T5 Tubes | 18W–28W, 2700K–6500K, CRI >80, direct replacement | Retrofit projects, commercial interiors |
Worldwide Distribution Network
We maintain a proven supply chain supporting projects across 50+ countries, with regional expertise tailored to local requirements:
| Region | Key Markets | Notable Project Types |
|---|---|---|
| Europe | Germany, France, UK, Spain | Public infrastructure, retail chains |
| North America | USA, Canada | Commercial retrofits, municipal lighting |
| Asia-Pacific | Australia, Japan, South Korea, Singapore | High-end architectural projects, hospitality |
| Other Regions | Russia, Middle East | Industrial facilities, outdoor security |
OEM/ODM Capabilities
Our engineering team delivers end-to-end customization for complex project needs:
Optical Customization: Adjustable beam angles, color temperatures, and CRI values
Mechanical Adaptation: Custom housings, mounting systems, and form factors
Full Project Support: From prototyping to mass production, including photometric testing and regulatory documentation
Connect for Project-Specific Solutions
For technical specifications, sample requests, or custom quotation inquiries, contact our global sales team directly:
Email: [email protected]
Phone: +86 139 0288 5704
Beauty STC Lighting: Engineering excellence for global lighting projects since 1998.
